Shenzhen avsuka Electronic Co., Ltd

Ø Support H.265 encoding, ultra-low bitrates, compatible with H.264 surroundings;

Ø Support VGA, HDMI full HD output simultaneously;

Ø Support ONVIF; access third party;

Ø Support multiple cloud technology, network penetration, alarm information pushed to your phone and other functions;

Ø Support various mobile monitoring (iPhone, Android);

Ø Remote Access, With DNS (ARSP),easy to monitor remotely

Ø Support UTC, control signal& video stream transmit through one single coaxial

Ø Support XVI/AHD/TVI/CVI/CVBS/IP six signals;

Ø Support intelligent analysis: functions like Perimeter alert、item retention、Video diagnosis、intelligent fast play and intelligent retrieval

System	Main processor	Hi3531D
Interface	Preview	1/4/8/16
Video	Codec	H.265
	Monitor quality	VGA(1080P at most);HDMI(4K at most)
	Preview ability	165M@12fps/164M @15fps/16*3M@18fps
	Encode ability	165M@6fps；164M@8fps； 163M@10fps；161080P@12fps；
	Decode ability	165M@6fps；164M@8fps； 163M@10fps；161080P@12fps；
	Multi-mode input	Analog：165MP; 164MP；161080P；161080N; hybrid：164MP（analog）+164MP（network）, 84MP（analog）+84MP network：81080P+8960P ; 83M；45M
	Motion Detection	Each screen can be set to 192 (16 * 12) detection areas; multi-level sensitivity can be set (Limited local channel)
Audio	Audio compression	G.711A
	Intercom	support
Record & playback	Record mode	manual>alarm>motion detection>timing
	Local Playback	16ch(analog input mode)
	Search mode	Search by time, calendar, event, channel
Storage & backup	Video storage	HDD, network
	Backup mode	Network, USB hard disk, USB burner, SATA burner
External Interface	Video input	16ch BNC
	Video output	1ch VGA, 1ch HDMI
	Loop Vout	N/A
	Audio I/O	2(Can be extended to 6ch)/1
	Alarm I/O	0（Can be extended to 4ch）/0（Can be extended to 1ch）
	Network interface	RJ45 10M/100M self-adaption
	PTZ control	1*RS485, Support kinds of PTZ protocols
	USB	2* USB 2.0 ports
	HDD	1*SATA ports (Max 8TB/per)
