System |
Main processor |
Hi3531D |
|
Interface |
Preview |
1/4/8 |
|
Video |
Codec |
H.265+/H.265/H.264+/H.264 |
|
Monitor quality |
VGA(1080P at most);HDMI(4K at most) |
|
|
Preview ability |
8*4K@15fps / 8*5M@20fps（6 in 1）/8*4M |
|
|
Encode ability |
8*4K@8fps / 8*5M@14fps /8*4M@18fps /8*3M@21fps /8*1080P |
|
|
Decode ability |
4*4K@8fps /8*5M@14fps /4*5M@18fps / 8*1080P@18fps |
|
|
Multi-mode input |
analog：8*4K; 8*5M; hybrid：4*4K（analog）+4*4K（network）4*5M（analog）+4*5M（network） network：8*3M ;4*5M |
|
|
Motion Detection |
Each screen can be set to 192 (16 * 12) detection areas; multi-level sensitivity can be set (Limited local channel) |
|
|
Audio |
Audio compression |
G.711A |
|
Intercom |
support |
|
|
Record & playback |
Record mode |
manual>alarm>motion detection>timing |
|
Local Playback |
8ch(analog input mode) |
|
|
Search mode |
Search by time, calendar, event, channel |
|
|
Storage & backup |
Video storage |
HDD, network |
|
Backup mode |
Network, USB hard disk, USB burner, SATA burner |
|
|
External Interface |
Video input |
8ch BNC |
|
Video output |
1ch VGA, 1ch HDMI |
|
|
Loop Vout |
N/A |
|
|
Audio I/O |
4(Can be extended to 8ch)/1 |
|
|
Alarm I/O |
0（Can be extended to 4ch）/0（Can be extended to 1ch） |
|
|
Network interface |
RJ45 10M/100M self-adaption |
|
|
PTZ control |
1*RS485, Support kinds of PTZ protocols |
|
|
USB |
3* USB 2.0 ports |
|
|
HDD |
2*SATA ports (Max 8TB/per) |
