Shenzhen avsuka Electronic Co., Ltd

4-in-1 HDTVI/HDCVI /AHD / CVBS optional output

UHD resolution 2560×1944P CMOS sensor

Ultra low illumination 0.01Lux

Up to 300M long distance and high speed real time monitoring

OSD menu control up the coaxial cable (UTC)

Low light and prefect night vision

Day/Night (ICR), AWB, AGC, DNR

Lightning protection

Strong water-proof housing, IP66

4pcs Array IR Leds, IR distance 70-80 meters

2.7-13.5 mm varifocal lens

Image Sensor	1/2.8" 5 Mega pixels Sony IMX335 CMOS
Chipset	IMX335+FH8538M
Effective Pixels	2560(H)×1944 (V)
Video Resolution	5MP:HDTVI/AHD:20fps@2560×1944P, 4MP:HDCVI/HDTVI/AHD:25/30fps@2560×1440P, CVBS:25/30fps@960H
Electronic Shutter	AUTO, 1/25 - 1/50,000s
Min. Illumination	0.01Lux@F1.2(AGC ON), 0Lux IR on
Video System	PAL/NTSC
Video Output	1 channel, HDCVI / HDTVI/AHD/CVBS , adjustable
Video Switch	DIP switch
Day/Night	Auto/Color/(B/W)/EXT
White Balance	ATW/Manual
DNR	2D NR
OSD Menu	Multiple languages OSD menu control up the coaxial cable (UTC)
Other Function	AWB, AGC, BLC
IR Led
IR Led	4pcs Array IR Leds
IR Distance	70-80 M
Lens
Focal length	2.7-13.5 mm varifocal lens
General
Power Supply	12 VDC ± 10%
Power Consumption	< 5 W
Operating Temp.	-20℃-(+60)℃, 10%-90%RH
Transmission Distance	Over 200m via 75-3 coaxial cable
