4-in-1 HD CVI / HD TVI/AHD / CVBS optional output

1/2.9" Sony IMX323 CMOS sensor

Full HD resolution 1920 x 1080P

Ultra low illumination 0.01Lux

Up to 300M long distance and high speed real time monitoring

OSD menu control up the coaxial cable (UTC)

Low light and wide dynamic range

Day/Night (ICR), ATW,AGC, BLC, DNR, D-WDR

Lightning protection

Strong water-proof housing, IP66

3D DNR

2PCS Array IR Leds, IR distance 20-30meters

3.6mm fixed lens

Image Sensor	1/2.9" 2 Mega pixels CMOS
Chipset	FH8536H+IMX323
Effective Pixels	1985(H)×1105 (V)
Video Resolution	1080P@25/30fps
Electronic Shutter	1/50s~1/60,000s
Min. Illumination	0.01Lux@F1.2(AGC ON), 0 Lux IR on
Video System	PAL/NTSC
Video Output	1 channel, HDCVI / HDTVI/AHD/CVBS , adjustable
Video Switch	2 bit switch
Day/Night	Auto(ICR) /Color / B /W
WDR	Digital WDR
OSD Menu	Support,coaxial cable contol via DVR directly (UTC)
Other Function	ATW,AGC,BLC,DNR
IR Led
IR Led	2PCS Array IR Leds
IR Distance	20-30 M
Lens
Focal length	3.6mm fixed lens
General
Power Supply	12 VDC ± 10%
Power Consumption	< 5 W
Operating Temp.	-20℃-(+60)℃, 10%-90%RH
Transmission Distance	Over 300M via 75-3 coaxial cable
