1/2.8" Sony STARVIS CMOS sensor

FHD resolution 1920 x 1080P

Low illumination 0.001Lux

Day/Night, AWB/MWB,BLC, HLC, 2D/3D-DNR,Shutter, IR-CUT

D-WDR, Mirror, Defogging

Multiply Style OSD Overlay,Motion Detection, Privacy Mask

RTSP and Onvif 17.06 compatible with many third-party NVR

H.264/H.265 dual-stream media server

Easy-to-use P2P Cloud service

Support user authentication, video data encryption

Support Alarm Snapshot to Email and FTP

Multiply WEB browser IE,Firefox 32bit ESR, PC Client, Mobile APP remote access

Lightning protection 4000V

Strong water-proof housing IP65

2 pcs SMD Array IR Leds, IR distance 10-20 meters

Network PTZ control , 5 times optical zoom

HD 2.8 – 13.5 mm AF lens

Camera
Image Sensor	1/2.8" Sony STARVIS CMOS
Effective Pixels	2 megapixels
Electronic Shutter	AUTO
Min. Illumination	0.001Lux@F1.2(AGC ON)
Day/Night	Auto/Color/(B/W)/Timing
WDR	Digital WDR
White Balance	Auto
AGC/BLC/HLC	Support
DNR	2D/3D DNR
Other	Multi-lines OSD, Motion Detection, Privacy Mask, Mirror, Flip
Encode
Video Standard	H.265/H.264
Video Resolution	Main Stream:25fps@1080P/720P Sub Stream: VGA(640x480)/360P/QVGA@25fps, etc.
Video Bitrates	32Kbps - 8Mbps, VBR/CBR
Audio Standard	G.711-u/G.711-a
IR Led
IR Led	12 pcs SMD IR Leds
IR Distance	20-30 M
Smart IR	Support (IR on illumination level adjustable)
Lens
Focal length	5X optical lens 2.8-13.5mm
Optional Function
POE, Audio, etc.
PTZ
Pan/Tilt Range	Pan: 0° ~ 350°; Tilt: 0° ~ 90°
Preset Point	128
Manual Control Speed	Pan: 0.5° ~80° /s; Tilt: 0.5° ~60° /s
Power-off Recovery	Support
Network Services
Protocol	HTTP/RTSP/FTP/SMTP/DHCP/NTP, etc.
P2P	Yes
Web	IE , Firefox 32bit ESR, etc.
Media	CMS, Android, IOS
ONVIF	17.06 compatible
General
Network Port	1-RJ45, 100Mbps, POE optional
Power Supply	12 VDC ± 10%
Power Consumption	< 5 W
Operating Temp.	-20℃-(+60)℃, 10%-90%RH
