1080p HD video, h.265 video coding, downward compatibility with H.264, dual bitstream;
It supports OLED display of equipment status: 4G signal strength, dialing status, positioning status, battery power, storage capacity and other equipment status information;
4G full Netcom, supporting any operator network;
It supports APN and VPN working mode;
Built in GPS / BeiDou module for precise positioning;
It has built-in WiFi, which can support AP and sta working modes at the same time;
|
Operating system
|
Linux
|
|
video
|
format
|
H.265/H.264
|
|
Double bitstream
|
YES
|
|
resolving power
|
1080P/720P/D1
|
|
|
|
|
audio
|
Intercom
|
two-way
|
|
display
|
yes
|
0.91 inch double color OLED display screen,
It can display equipment operation information
|
|
Local control
|
yes
|
3D control keyboard (optional）
|
|
storage
|
yes
|
TF card
|
|
WIFI
|
5G/4G/3G
|
yes
|
|
WIFI
|
802.11b/g/n
|
|
AP
|
YES
|
|
GPS
|
GPS
|
GPS/BD
|
|
Extension interface
|
RJ45 network interface, analog video output, 485 interface, charging interface
|
|
camera
|
Sensor
|
1/2.8" Progressive Scan CMOS
|
|
system
|
PAL/NTSC
|
|
illumination
|
colour：0.05Lux @ (F1.6，AGC ON)
night：0.01Lux @(F1.6，AGC ON)
|
|
Signal
|
≧52dB
|
|
sec
|
1/1s ~ 1/30,000s
|
|
lens
|
20x
|
|
resolving
|
1920x1080/1280*720 25fps/30fps
|
|
colour balance
|
Automatic 1 / automatic 2 / indoor / outdoor / manual / sodium lamp / fluorescent lamp
|
|
3D
|
yes
|
|
IR
|
60-80M
|
|
PTZ
|
PTZ
|
PELCO-D/P
|
|
Horizontal
|
360°
|
|
Vertical
|
0°~90°
|
|
Power
|
Battery
|
10400MA
|
|
charging time
|
<4t
|
|
Working hours
|
>8t
|
|
work environment
|
temperature
|
-20℃～ +60℃
|
|
humidity
|
<90%
|
|
size
|
|
244*146mm（Hmax*Dmax）
|
|
kg
|
Net weight:4kg
|
|
Gross weight：11kg
|
Standard accessories:
IP67 protection box * 1 / triangle bracket * 1 / tray * 1 / charger * 1 / 220 V power line * 1 / aviation line * 1
