4-in-1 HDTVI/HDCVI /AHD / CVBS optional output

4K resolution 3840 x 2160P

Ultra low illumination 0.01Lux

Up to 300M long distance and high speed real time monitoring

OSD menu control up the coaxial cable (UTC)

Day/Night (ICR), ATW, AGC, BLC, 2D/3D-DNR

IR-Smart, Mirror, Flip, Rotate, LSC

Lightning protection

Strong water-proof housing, IP66

4 pcs new IR Leds, IR distance 15-20 meters

3.6mm fixed lens

Image Sensor	8Mega pixels CMOS
Chipset	1/2.3” OV12895+NVP2481H
Effective Pixels	3840(H)×2160 (V)
Video Resolution	8MP:HDTVI/CVI/AHD:15fps@3840x2160P, CVBS:25/30fps@960H
Electronic Shutter	AUTO, 1/25 - 1/50,000s
Min. Illumination	0.01Lux@F1.2(AGC ON), 0Lux IR on
Video System	PAL/NTSC
Video Output	1 -BNC, HDCVI / HDTVI/AHD/CVBS , adjustable
Video Switch	Dip Switch
Day/Night	Auto/Color/(B/W)/EXT
Shutter	AUTO/FLK
White Balance	ATW
AGC/BLC	Support
DNR	2D 3D NR
OSD Menu	Multiple languages OSD menu control up the coaxial cable (UTC)
Other	IR-Smart, Mirror, Flip, Rotate, LSC
IR Led
IR Led	4 pcs IR Leds
IR Distance	15-20 M
Lens
Focal length	3.6mm fixed lens
General
Power Supply	12 VDC ± 10%
Power Consumption	< 5 W
Operating Temp.	-30℃-(+60)℃, 10%-90%RH
